B&K Precision - BK Precision 1901B-220V Switching DC Power Supply, 220V, 1-30V. Model 1901B-220V - 01BK1901-220V

Models 1900B, 1901B, and 1902B are laboratory grade switching mode DC power supply with high current output in a small form factor and lightweight package. The supplies provide various configurations of high output voltage or high output current and make setting voltage and current levels fast and precise through its dual action, coarse/fine rotary encoder control. In addition to constant voltage (CV) and constant current (CC) modes, the high efficiency DC power supplies offer a unique solution with its preset and remote control modes. Save up to three different presets of voltage and current values for quick recall. The remote control function allows the output power, voltage, and current to be adjusted without touching the front panel of the power supply. A remote sensing terminal is also available for use to compensate for long output line losses.

Features:

• Automatic CV/CC crossover operation
• Lightweight and compact
• Rotary encoder control for precise voltage and current setting
• 3 user-defined voltage and current presets
• USB interface with PC software for remote control and external timed programming
• Analog remote control function
• Overvoltage, overtemperature, and overload protection
• Remote sense

Applications:

• Production Testing
• Telecommunications
• R&D
• Service
• University Labs

Specifications:

• Variable Output Range Voltage: 1 to 32 V
• Current: 0 to 30 A
• Auxiliary Output Current: 5 A
• Maximum Output Power: 960 W
• Regulation Load Voltage: ≤50 mV at 0 to 100% Load
• Current: ≤150 mA at 10 to 90% Rated Voltage
• Line:
• ≤20 mV at 90 to 132 VAC and 170 to 264 VAC Variations
• ≤50 mA at 90 to 132 VAC and 170 to 264 VAC Variations
• Ripple & Noise Voltage RMS: ≤5 mV
• Peak-Peak: ≤50 mV
• Current Ripple & Noise:
• ≤50 mA (110 VAC)
• ≤40 mA (230 VAC)
• Operating Temperature: 32 to 104°F (0 to 40°C), ≤80% R.H.
• Storage Temperature: 5 to 158°F (-15 to 70°C), ≤85% R.H.
• Dimensions: 7.9 x 3.5 x 10.8" (200 x 90 x 275 mm)
• Weight: 7 lbs (3.2 kg)
